FANTOM-06, FANTOM-07, FANTOM-08: Keep Pedal Functions Fixed Across Scenes and Tones

The functions that can be controlled using a pedal connected to the PEDAL CTRL 1, 2/L, 3/C jacks on the FANTOM-0 can be configured to use either the system settings or the scene settings.

When “Pedal Assign Source” is set to “SYS”, the instrument operates with the functions assigned to “Pedal 1–2 Assign” in the system settings, regardless of the tone or program.

Follow the steps below.

1. Press the [MENU] button.
   - The MENU screen appears.
2. Touch <SYSTEM>.
   - The SYSTEM screen appears.

3. Select the “PEDAL” tab with the [E1] knob.
4. Use the [E2] knob to select “Pedal Assign Source”.
5. Use the [E6] knob to select “SYS”.
6. Press the [WRITE] button.
